Plug-In Electronic Transformers for LED and Halogen Lighting

Power and Convenience at Your Fingertips!

Plug-In-Diming-Electronic-Transformer

Features

  • *Optional Integrated Dimmer  (*Only Available in AC Output Models)
  • Integrated On/Off Switch
  • Available Wattages: 10W – 60W
  • Input: 120V AC 50/60Hz
  • Output Voltages: 12V or 24V, AC or DC
  • Soft Start Technology
  • Short Circuit Protection
  • Auto Reset and Thermal Protection
  • Available in Black or White Finish
Request a Quote Now
Compatible with Emery Allen and Soraa
Model Series Wattage Input Output Voltage Load Type Dimming Options Data Sheet
TA10WA12PL1 10W 120V AC 0.08A 50/60Hz 12V AC 12V AC LED, Halogen 0.83A Max. Integrated Dimmer, ELV TA10WA12PL1 120V AC 50/60Hz Input 10W 12V AC Wall Plug In Electronic Transformer Spec Sheet
TA10WA24PL1 10W 120V AC 0.08A 50/60Hz 24V AC 24V AC LED, Halogen 0.42A Max. Integrated Dimmer, ELV TA10WA24PL1 120V AC 50/60Hz Input 10W 24V AC Wall Plug In Electronic Transformer Spec Sheet
TA10WD12PL1 10W 120V AC 0.08A 50/60Hz 12V DC 12V DC LED 0.83A Max. ELV TA10WD12PL1 120V AC 50/60Hz Input 10W 12V DC Wall Plug In Electronic Transformer Spec Sheet
TA10WD24PL1 10W 120V AC 0.08A 50/60Hz 24V DC 24V DC LED 0.42A Max. ELV TA10WD24PL1 120V AC 50/60Hz Input 10W 24V DC Wall Plug In Electronic Transformer Spec Sheet
TA15WA12PL1 15W 120V AC 0.12A 50/60Hz 12V AC 12V AC LED, Halogen 1.25A Max Integrated Dimmer, ELV TA15WA12PL1 120V AC 50/60Hz Input 15W 12V AC Wall Plug In Electronic Transformer Spec Sheet
TA15WA24PL1 15W 120V AC 0.12A 50/60Hz 24V AC 24V AC LED, Halogen 0.625A Max Integrated Dimmer, ELV TA15WA24PL1 120V AC 50/60Hz Input 15W 24V AC Wall Plug In Electronic Transformer Spec Sheet
TA15WD12PL1 15W 120V AC 0.12A 50/60Hz 12V DC 12V DC LED 1.25A Max ELV TA15WD12PL1 120V AC 50/60Hz Input 15W 12V DC Wall Plug In Electronic Transformer Spec Sheet
TA15WD24PL1 15W 120V AC 0.12A 50/60Hz 24V DC 24V DC LED 0.625A Max ELV TA15WD24PL1 120V AC 50/60Hz Input 15W 24V DC Wall Plug In Electronic Transformer Spec Sheet
TA30WA12PL1 30W 120V AC 0.25A 50/60Hz 12V AC 12V AC LED, Halogen 2.5A Max Integrated Dimmer, ELV TA30WA12PL1 120V AC 50/60Hz Input 30W 12V AC Wall Plug In Electronic Transformer Spec Sheet
TA30WA24PL1 30W 120V AC 0.25A 50/60Hz 24V AC 24V AC LED, Halogen 1.25A Max Integrated Dimmer, ELV TA30WA24PL1 120V AC 50/60Hz Input 30W 24V AC Wall Plug In Electronic Transformer Spec Sheet
TA30WD12PL1 30W 120V AC 0.25A 50/60Hz 12V DC 12V DC LED 2.5A Max ELV TA30WD12PL1 120V AC 50/60Hz Input 30W 12V DC Wall Plug In Electronic Transformer Spec Sheet
TA30WD24PL1 30W 120V AC 0.25A 50/60Hz 24V DC 24V DC LED 1.25A Max ELV TA30WD24PL1 120V AC 50/60Hz Input 30W 24V DC Wall Plug In Electronic Transformer Spec Sheet
TA45WA12PL1 45W 120V AC 0.38A 50/60Hz 12V AC 12V AC LED, Halogen 3.75A Max Integrated Dimmer, ELV TA45WA12PL1 120V AC 50/60Hz Input 45W 12V AC Wall Plug In Electronic Transformer Spec Sheet
TA45WA24PL1 45W 120V AC 0.38A 50/60Hz 24V AC 24V AC LED, Halogen 1.875A Max Integrated Dimmer, ELV TA45WA24PL1 120V AC 50/60Hz Input 45W 24V AC Wall Plug In Electronic Transformer Spec Sheet
TA45WD12PL1 45W 120V AC 0.38A 50/60Hz 12V DC 12V DC LED 3.75A Max ELV TA45WD12PL1 120V AC 50/60Hz Input 45W 12V DC Wall Plug In Electronic Transformer Spec Sheet
TA45WD24PL1 45W 120V AC 0.38A 50/60Hz 24V DC 24V DC LED 1.875A Max ELV TA45WD24PL1 120V AC 50/60Hz Input 45W 24V DC Wall Plug In Electronic Transformer Spec Sheet
TA60WA12PL1 60W 120V AC 0.5A 50/60Hz 12V AC 12V AC LED, Halogen 5A Max Integrated Dimmer, ELV TA60WA12PL1 120V AC 50/60Hz Input 60W 12V AC Wall Plug In Electronic Transformer Spec Sheet
TA60WA24PL1 60W 120V AC 0.5A 50/60Hz 24V AC 24V AC LED, Halogen 2.5A Max Integrated Dimmer, ELV TA60WA24PL1 120V AC 50/60Hz Input 60W 24V AC Wall Plug In Electronic Transformer Spec Sheet
TA60WD12PL1 60W 120V AC 0.5A 50/60Hz 12V DC 12V DC LED 5A Max ELV TA60WD12PL1 120V AC 50/60Hz Input 60W 12V DC Wall Plug In Electronic Transformer Spec Sheet
TA60WD24PL1 60W 120V AC 0.5A 50/60Hz 24V DC 24V DC LED 2.5A Max ELV TA60WD24PL1 120V AC 50/60Hz Input 60W 24V DC Wall Plug In Electronic Transformer Spec Sheet
